Separate Mounting of Distributor and Lubricator
Separatemountingofthedistributorandthelubricatorispossible.
Forthis,perma-tecoffersanadditionalmountingdevice,thenecessarytubeconnectionsandalongercon-
nectingcable(referto“AccessoriesandSpareParts”).
AttachthelubricatorofthePROrangetoyoursystemasdescribedinitsOperatingInstructionsandmountthe
distributorasfollows:
♦ Attachthemountingdevicetothedistributorusingtheenclosedhexheadbolts(M6x16)andthewashers.
♦ Screwthemountingdevicewiththedistributorontoasupportofyoursystem.
Fortheborepositionofthefourxingscrewsrefertogure7below.AtleastfourhexagonscrewsM6x25
mustbeused(e.g.onmetalground).
♦ Beforeyouconnecttheoutletsofthedistributortoanygreaselinesandhosesyouhavetopre-lubricateall
lubricationpointsandpre-llallgreaselineswiththesamelubricantthatiscontainedinthePROLCunit
ofthelubricator.Forthat,perma-tecoffersa400glubricationcartridgeformanually-operatedgreasepresses
withtherequestedlubricant.
♦ FitthereducercouplingG3/8itoG1/8if.tubeoØ8mm(Partno.101545)andthetubeconnectorG1/8o
fortubeoØ8mmstraight(Partno.101570)onthelubricator.
♦ FitthetubeconnectorG3/8ofortubeoØ8mmstraight(Partno.101498)onthedistributor.
♦ ConnectthedistributortothePROlubricatorwiththegreaseline.Maximumtubelength2meters(Ø8x1.5,
inner-Ø5mm).
♦ Connectthegreaselinestotheconnectionsofthedistributorandinstallthemcorrectlybetweenthe
distributorandthelubricationpoint.The grease line between lubricator, distributor and lubrication point
must not exceed a total length of 5 meters (for details about temperature and lubricant please refer to
operating instructions of PRO/PRO C chapter 3, chart 1).
♦ Fittheendsofthegreaselineswiththerequiredtubeconnections.
♦ Whilethelubricationsystemisswitched off,connectthelubricatortothedistributorwiththeconnecting
cable(long).
♦ Thelubricationsystemisnowreadyforoperation.
Ensurecorrectandtightassemblyoftheconnectionsandgreaselinestoavoidpossibleleakage.
75
45
gure7
2hexagonscrews
M6x25(forwall
mountingonmetal)
2hexheadbolts
M6x16,maximum
torque3Nm
(forattachingthe
distributortothe
mountingdevice)
2hexagonscrews
M6x25(forwall
mountingonmetal)
