Symbols for the air conditioning control panel
Image Function
This switch controls the source of the air flowing into the heater and air conditioner unit.
Recirculated air may reduce the amount of time needed to cool down the interior of the vehicle (when used with
A/C) and may also help reduce undesired outside odors from reaching the interior of the vehicle. This button can
be engaged manually in any non-defrost modes.
NOTE
You may notice changes in sound between recirculated mode and other airflow modes.
Turning this dial clockwise from the OFF position turns the fan ON and increases the fan speed.
This button turns the A/C compressor on and off. When using the Max Def function the user will not be able to turn
off the AC compressor with this button.
NOTE
Fan Control Dial must also be in the ON position for A/C to be on. A/C engages automatically in AUTO, de-
frost, and floor/defrost.
