Clutch Linkage
Have your authorized dealer service the
clutch according to the clutch
manufacturer’s service guidelines. This
vehicle is equipped with a rod and lever
mechanical clutch linkage. Lubricate each
pivot point on the clutch linkage. Replace
with the recommended fluid Component
Lubrication Index. Lubrication Specification
Chart on page 276
Clutch Adjustment
Clutch pedal free travel is usually 1 3/4 in.
to 2 in. (34 to 51 mm). This should be your
guide for determining whether your truck
needs clutch adjustment. Some vehicles
have automatic clutch adjustment. If yours
doesn’t have this feature, adjustment will
have to be done by a trained certified
mechanic. Have the adjustment done
before clutch pedal free travel is reduced to
the minimum allowable 1/2 in. (13 mm).
Under normal wear conditions, the clutch
will require periodic adjustment. See the
clutch manufacturer's Service Manual for
the proper adjustment procedures.
Specification Reference
Charts
Pipe and Hose Clamp Torque
Values
Torque specifications for engine parts.
Application Type of Clamp lb-in. N•m
Radiator and Heat Exchanger
Hoses
Constant Torque CT-L 90-110 10.2-12.5
Heater Hoses Constant Tension not required not required
Air Intake Pipes Hi Torque HTM-L 100-125 11.3-14.2
Plastic Air Intake Pipes Constant Torque CT-L 88 10.0
Charge Air Intake Hoses Flex Seal 70-100 7.9-11.3
B9296 50-60 6-7
MAINTENANCE - Specification Reference Charts
274 Y53-6076-1D1 (09/20)
