If the pressure indicated by your manifold
pressure gauge goes down, there may be
something wrong with your engine. Have it
checked by a qualified service person.
Drive Axle Temperature Gauge
(Forward and Rear)
These gauges indicate the temperature of
the lubricant in your vehicle's axle(s).
These temperatures will vary with the kind
of load you are carrying and the driving
conditions you encounter. Maximum axle
temperature may vary, depending upon the
axle and type of lubricant. Very high
temperatures signal a need to have your
axle lubrication checked.
CAUTION
Driving with very hot temperatures in
your rear drive axles can cause seri-
ous damage to axle bearings and
seals. Have your axle lubrication
checked if you notice a sign of over-
heating.
Depending on the vehicle configuration,
there may be a single gauge for more than
just the forward and rear driver. The icon
will have an "X" over the representative
axle to indicate which axle's temperature is
being displayed in the gauge.
Dash Switches
This custom vehicle will have a wide
variety of switch-controlled equipment.
However, this particular vehicle may not
have every switch identified in this section
of the operator manual. Some air device
switches on the dash may require that the
vehicle either be at a specific speed, have
park brakes set, or another device to be on
or off for the air device to operate. The
instrument display will show information
regarding what needs to change in order
for the air device to operate as expected.
The following table provides a complete list
of icons that may be found on the switch.
Title Standard or Optional
Axle, Differential Lock - Tridrive OPT
Axle, Diff-Lock - Dual OPT
Axle, Diff-Lock - Forward Rear OPT
Axle, Diff-Lock - Rear Rear OPT
Axle, Diff-Lock - Single Rear OPT
CONTROLS - Dash Switches
84 Y53-6076-1D1 (09/20)
