At first 15,000 mi / 24,000 km or at first PM
9
Inspect for visible damage, signs of Steering Components - Drag link Tube Clamp and Ball Socket
• Check the torque: tighten to specified torque value as required. (Refer to Steering System on page 265 for maintenance
instructions.)
Steering Components - Pitman Arm Clamp Bolt and Nut
• Check the torque: tighten to specified torque value as required. (Refer to Steering System on page 265 for maintenance
instructions.)
Steering Components - Steering Intermediate Shaft
• Check the torque on the pinch bolt and nut. (Refer to Steering Shaft Bolt Torque Specifications on page 267 for maintenance
instructions.)
Steering Components - Steering Intermediate Shaft U-joints (ON HIGHWAY)
• Lubricate [EP NLGI #2 HD grease, -10 to 325°F (-23 to 163°C) range]. (Refer to Steering System on page 265 for maintenance
instructions.)
Steering Components - Steering Intermediate Shaft U-joints (OFF HIGHWAY or CITY DELIVERY)
• Lubricate [EP NLGI #2 HD grease, -10 to 325°F (-23 to 163°C) range]. (Refer to Steering System on page 265 for maintenance
instructions.)
Steering Components - Drag link and Tie Rod Arm Ball Sockets (ON HIGHWAY)
• Lubricate (EP NLGI #2 lithium-based, moly-filled, HD grease). (Refer to Steering System on page 265 for maintenance
instructions.)
9
Ensure that all maintenance intervals leading up to this point are repeated during this interval prior to the completion of
those listed here.
MAINTENANCE - At first 15,000 mi / 24,000 km or at first PM
176 Y53-6076-1D1 (09/20)
