3. Reinstall the oil fill cap and twist to
lock it in place.
Install Engine Belt
You can extend the reliability and service
life of your vehicle's drive belts with proper
attention to installation and maintenance.
Neglect could cause belt failure. The result
could be the loss of the electrical or air
system as well as possible engine damage
from overheating.
NOTE
See the engine manufacturer's opera-
tor's manual for further information on
replacing engine drive belts.
The images below may not appear like the
configuration of the vehicle. The procedure
is still the same. Follow this procedure to
install an accessory drive belt:
1. Route the new belt around the
pulleys, and then rotate the
automatic tensioner so that the
idler pulley swings toward the belt
routing. The following figure shows
an example of the rotation direction
to release the tensioner.
2. Slip the belt around the idler pulley
attached to the automatic
tensioner.
3. Release the automatic tensioner.
4. Check the belt alignment on each
pulley. The belt must fall between
the flanges of each pulley.
Engine Fan
WARNING
DO NOT work on or near the fan with
the engine running. Anyone near the
engine fan when it turns on could be
injured. If it is set at MANUAL, the fan
will turn on any time the ignition key
switch is turned to the ON position. In
AUTO, it could engage suddenly with-
out warning. Before turning on the igni-
tion or switching from AUTO to MAN-
UAL, be sure no workers are near the
fan. Failure to comply may result in
death or personal injury.
Follow these guidelines to check your
engine fan:
• With the engine shut off, check the
fan hub bearings for looseness,
loss of lubricant, and any abnormal
MAINTENANCE - Engine Maintenance
Y53-6076-1D1 (09/20) 245
