this immediately. If you detect any
deficiencies, take the vehicle to an
authorized dealer for servicing. Delay could
lead to severe and expensive damage to
your vehicle.
Air Cleaners
WARNING
DO NOT use air filter housings as grab
handles. These components may
break if you are using them to support
your weight. Failure to comply may re-
sult in personal injury or damage to ve-
hicle components.
CAUTION
Failure to replace air filter at proper in-
tervals may result in passage of dirt/
debris into the engine or the “dusting”
of an engine resulting in significant
equipment damage.
Service the air cleaner filter elements as
specified in the Component Specific
Intervals on page 178. This vehicle is
equipped with an air inlet restriction
indicator. Service the filter elements when
the air inlet restriction indicator locks in the
extreme Up position. Paper elements
require care and proper handling because
they are critical to engine service life. If
your vehicle has an external air cleaner
and cab-mounted mirrors, the mirror must
be pivoted to provide access for servicing
the filter element.
Replacing the Engine Air Intake
Filter
1. Steps 1 and 6
2. Steps 2, 5, and 6
3. Steps 3 - 7
1. Loosen (do not remove) upper 5/16
in. mounting hardware.
2. Remove acorn nut and flat washer,
then pivot upper stabilizer rod away
from cab.
MAINTENANCE - Engine Maintenance
Y53-6076-1D1 (09/20) 247
