Symbol Name Color
Standard or
Optional
Refrigerator on page 83 Green OPT
Seat Belt Fasten Red STD
Suspension, Lift Axle White OPT
Tire Inflation (TPMS) on page 83 Yellow OPT
Transmission, Auxiliary on page 83 Yellow OPT
Transmission, Check on page 83 Red OPT
Turn Signal, Left on page 83 Green STD
Turn Signal, Right on page 83 Green STD
Axle, Stability Control (Option)
Calculates the driver’s intended path of
travel from wheel speed and steering angle
sensors, then compares calculations to the
actual direction of travel. The system uses
individual wheel brakes to re-adjust the
path of the vehicle.
• The Stability Control Icon (ESC or
Electronic Stability Control)
illuminates during the Bulb Check
when the ignition is turned ON. It
turns off after a few seconds if no
system problems are detected. If a
problem is detected, the ESC
Warning lamp will turn on and stay
on.
• Illuminates when the ESC system
is regulating individual wheel
brakes to correct the vehicle’s
direction of travel. (Refer to
Advanced ABS with Stability
Control for more information.)
CONTROLS - Guide to the Warning Symbols
76 Y53-6076-1D1 (09/20)
