Illuminates during the bulb check. Have the
ABS system checked by an authorized
dealer if the ABS Warning Lamp stays on
for more than 3 seconds.
• Illuminates during normal operating
conditions to indicate a problem
with the ABS system.
• Illuminates when a problem exists
with Automatic Traction Control
(ATC).
Brake, Park Brake
Illuminates in the status indicator when
parking brakes are applied.
Brakes, Low Air
Illuminates when system air pressure falls
below 60 psi.
Brakes, Trailer Antilock Brake
System
Illuminates during the bulb check and the
tractor/truck is connected with a ABS
equipped trailer. Illuminates during normal
operating conditions to indicate a problem
with the Trailer ABS System. This should
be checked by an authorized dealer as
soon as possible.
NOTE
Tractors/Trucks and trailers built after
03/01/2001 must be able to turn on an
In-Cab Trailer ABS Warning Light (per
U.S. FMVSS121). The industry chose
Power Line Communication (PLC) as
the standard method to turn it on. On
trailers built prior to 03/01/2001 verify
trailer ABS system status via the re-
quired external warning light mounted
on the trailer. The indicator light on the
trailer should be yellow and identified
with the letters ABS.
Cruise Control
This indicator shows the operator which
Cruise Control function is currently enabled
or active. This includes
• Cruise Control
• Adaptive Cruise Control (optional)
• Predictive Cruise Control (optional)
• Variable Road Speed Limiter
(optional)
When a Cruise Control function is enabled,
a white indicator will appear. When a
Cruise Control function has been activated,
the indicator will change from white to
green. For more information on use of the
various Cruise Control functions, see
Cruise Control, Adaptive Cruise Control,
CONTROLS - Guide to the Warning Symbols
78 Y53-6076-1D1 (09/20)
