PREPARE
Preparing Your Pet Door
• Read this entire guide prior to cutting or modifying an opening in
your door or wall.
• Do not proceed with cut-out or installation until all steps in this
section have been completed. Do not remove sensitivity sticker until
after installation.
Place Batteries in the Pet Door
1. With a Phillips screwdriver, remove the two
Battery Compartment Cover screws.
2. Remove the Battery Compartment Cover.
3. Refer to the inside of the Battery
Compartment Cover for the proper
orientation of the four D-Cell
(LR20) batteries.
4. Replace the Battery Compartment Cover
and re-install the two screws.
5. When the batteries are placed in the Pet
Door the red light will illuminate for two
seconds and the flap will move into the
locked position, unless the flap is already in
the locked position.
NOTE: The door must be in the upright position for the flap to centre properly and
operate correctly.
Place Battery in the SmartKey
™
Electronic Key
1. Place the PetSafe
®
RFA-67 battery into the
bottom of the SmartKey
™
Electronic Key.
2. Using a coin, rotate one-quarter turn
clockwise to secure the PetSafe
®
RFA-67 battery.
NOTE: The SmartKey
™
Electronic Key has a red light that will flash when the PetSafe
®
RFA-67 battery is low; the battery should be replaced as soon as possible.
STEP 1
STEP 2
