Controls
7 - 1
Fig. 7 - 01
7 Controls
7.01 On/off switch
● Turn the machine on and off by turning
the on/off switch 1.
The switch in the illustration
can be found on machines with
Quick motors. When other
motors are used, other
switches may be fitted.
1
7.02 Pedal
0 = Neutral position
1 = Sew
For other pedal functions see
the motor instruction manual.
Fig. 7 - 02
0
1
