Pfaff 1193 - Limiting the Stitch Length

Adjustment
11 - 19
11.21 Limiting the stitch length
The maximum stitch length can be limited mechanically.
2
4
3
● Set the required maximum stitch length on the adjustment knob 1.
● Move crank 2 (screws 3) from above to rest on stop 4.
Fig. 11 - 18
1
