Adjustment
11 - 4
11.06 Setting the feed dog at the neutral position
Requirement
With the stitch length set at "0", the cranks 1 and 3 must be in alignment, and there
should be no driving motion of the feed dog when the balance wheel is turned.
● Raise the roller presser and set the stitch length at "0".
● Turn crank 1 (screw 2) in accordance with the requirement.
Fig. 11 - 03
3
2
1
