Rüsten
9 - 4
9.04 Changing the bobbin / threading the bobbin thread
Turn the machine off!
Danger of injury if the machine
is started accidentally!
● Raise take-up lever as far as possible.
● Open the post cap, raise latch 1 and
remove bobbin.
● Insert the full bobbin into the hook drive
in such a way that the bobbin rotates in
the direction of the arrow when the
thread is pulled.
● Close latch 1.
● Pull the thread under the spring into the
hole through slot 2.
● Close the post cap.
Do not operate the machine
when the post cap is open!
Danger of injury by the hook!
Fig. 9 - 04
9.05 Adjusting the bobbin thread tension
Turn the machine off!
Danger of injury if the machine
is started accidentally!
● Open the post cap.
● Adjust the bobbin thread tension by
turning screw 1.
● Close the post cap.
Do not operate the machine
when the post cap is open!
Danger of injury by the hook!
1
2
Fig. 9 - 05
