Pfaff 1193 - Needle Thread Tension Release (on the PFAFF 1193)

Adjustment
11 - 12
11.14 Needle thread tension release (on the PFAFF 1193)
Requirement
With the presser bar lifter
11
11
1 raised, the tension discs
44
44
4 must be at least
0.5 mm0.5 mm
0.5 mm0.5 mm
0.5 mm apart.
● Raise the presser bar lifter 1.
● Adjust the thread tension 2 (screw 3) in accordance with the requirement
..
..
.
Fig. 11 - 11
0,5 mm
4
2
1
3
