Adjustment
10
13.04.05 Pre-adjusting the needle height
Requirement
With the needle bar at its bdc the distance between the needle bar and the needle plate
must be 15 mm.
Move the needle bar 1 (screw 2) in accordance with the requirement without twisting it.●
Fig. 13 - 05
2
1
