Pfaff 335 Adjustment Manual

Adjustment
31
13.06 Parameter settings
(only on machines with Quick-EcoDrive and control unit P40ED)
The selection of the user level and the alteration of parameters is described in the sepa-
rate instruction manual for the drive unit.
●
Further parameters and the description for an internet update of the machine
software and reset /cold start of the machine can be found in the instruction
manual for the control panel.
13.06.01 Parameter list
Group Parameter Description User lever Setting range Set value
1
105 Speed for start backtack B, C 300 - 2000 800
110 Speed for end backtack B, C 300 - 2000 1000
6
607 Speed max. B, C 300 - 2000
▲
609 Cutting speed 1 B, C 60 - 300 180
7
700
Needle position 0 (needle reference position)
B, C 0 - 255
*
702 Needle position 1 (needle lowered) B, C 0 - 255 85
703 Needle position 2 (take-up lever raised) B, C 0 - 255 230
705 Needle position 5 (end cutting signal 1) B, C 0 - 255 100
706 Needle position 5 (start cutting signal 2) B, C 0 - 255 85
707 Needle position 9 (start thread tension
release/start thread catcher)
B, C 0 - 255 195
722 Acceleration ramp B, C 0 - 255 50
723 Brake ramp B, C 0 - 255 40
734 Tact output A2 (thread trimming) B, C 001 - 009 0
760 Multiplier for the fi xed value (200)
stitch count
A,B,
C
0 - 250 5
799 Selected machine class C 1 - 4 2
8
800 Rotating direction of the motor C 0 - 1 1
884 Proportional sensitivity of the speed
control unit
B,C 03 - 24 10
897 Variant mini-motor, 1 = long, 2 = short C 0 - 1 0
9
900 Additional P- sensitivity of the
speed control unit
B,C 1 - 24 9
▲
See Chapter 3 Specifi cations
*
Adjustment see Chapter 8.04 Basic position of the machine drive unit (in the machine instruction
manual).
