Controls
7 - 3
Fig. 7 - 05
7.05 Presser bar lifter
● The presser foot is raised by turning
presser bar lifter 1.
Fig. 7 - 06
7.06 Feed regulator wheel
● The stitch length is set by turning
regulator wheel 1.
1
1
