Pfaff 422

Adjustment
11 - 7
11.04.06 Lifting stroke of feed dog
Requirement
With the needle bar at b.d.c. the feed dog must be in its highest position.
Fig. 11 - 06
● Loosen screw 1 and undo screw 2 by a half turn.
● Turn clamp 3 according to Requirement, then first tighten screw 2 and afterwards screw 1.
1
2
3
