Adjustment
11 - 31
11.06 Parameter adjustments
On the control panel the paramaters can be adjusted on the display.
6 601 Trimming
l = yes l
ll = no
609 Trimming speed 1 30 - 300 180
7 700 Needle position 0 0 - 239
Reference position of needle
701 Angle position
I = Adjusting synchroniser with l
balance wheel
II = Adjusting synchroniser with
keys " + " und " - "
702 Needle position 1 (needle down) 0 - 239 75
703 Needle position 2 0 - 239 213
(take-up lever up)
705 Needle position 5 0 - 239 175
(end of trimming signal 1)
707 Needle position 9 0 - 239 180
(start of tension-release signal 2)
Group
Parameter
Meaning Adjustm. range Standard setting
For further displays and information please see instruction manual of motor
manufacturer.
