Pfaff 422

To Next Page

To Previous Page

Adjustment

11 - 20

11.04.18 Presser foot pressure

Requirement

The material must be reliably fed, even at the highest sewing speed.

Fig. 11 - 18

● Adjust screw 1 according to Requirement.
