Care and maintenance
10 - 2
Switch the machine off!
Danger due to unintentional starting of the machine!
Check the oil level every time before operation!
There must always be oil in container 1!
● If required, pull knee lever out towards front and tilt machine back.
● Top up oil container 1 through hole 2 to the mark.
● Before initial operation and when the machine has stood for a long time, apply 1 to 2
drops of oil into hole 4 of the hook gib on both hooks in addition.
● To set the machine upright press tilt lock 3 and position the machine upright with both
hands.
When setting the machine upright always hold it with both hands!
Danger of crushing your hands between table cutout and machine!
Only use oil with a medium viscosity of 22.0 mm²/s at 40° C and a density of
0.865 g/cm³ at 15 C.
We recommend PFAFF sewing mahine oil, No. 280-1-120 144.
Fig. 10 - 03Fig. 10 - 02
3
10.02 Oiling the hook
1
2
4
