Mounting and commissioning the mac
hine
8 - 7
1
76-057
8
.01.08
Mounting the bottom V-belt guard
●
Align V-belt guard
1
so that the motor
pulley and V-belt are run freely.
●
Tighten screw
2
.
8
.01.09
Fitting the thread guide
●
Fit the tapered thread guide pin
1
into the
corresponding hole in the machine
housing.
Fig. 8 - 10
1
2
Fig. 8 - 09
23
25
