Pfaff 9063 - Position of the Stationary Knife

Adjustment
11 - 12
Fig. 11 - 11
11.05.03 Position of the stationary knife
Requirement
The stationary knife 1 should be at a distance of 3.5 mm from the centre of the needle.
● Adjust stationary knife 1 (screws 2) in accordance with the requirement.
For technical reasons it may be necessary to alter the specified basic position:
Move stationary knife 1 towards "+" (= more thread) or towards "-" (= less
thread).
76-039
2
1
3,5 mm
+
-
