Adjustment
11 - 3
11.04.02 Setting the bottom feed dog at its neutral position
Requirement
With the stitch length set at "0", cranks 1 and 3 should be in alignment, and there should be
no feeding motion of the bottom feed dog when the balance wheel is turned.
Fig. 11 - 02
● Raise the presser foot and set the stitch length at "0".
● Adjust crank 1 (screw 2) in accordance with the requirement.
76-026
3
2
1
