1. Select stitch 45 from the Group 2-B stitches
to get the bar tack stitch. The stitch width and
stitch length can be . Change to the
fancy stitch foot "1A".
adjusted
2. Position the needle at the top edge of the
pocket opening.
3. Press the START/STOP button or push on the
foot control to start sewing.
When the bar tack has reached the desired
length push the Auto-lock button. Machine will
sew locking stitches and stop.
4. Illustration shows sewing procedure for bar
tack.
5. Example of sewn bar tacks at pocket corners
is shown.
Note: Reinforce points that will be subject
to strain such as pocket corners.
62
1.0~3.0
0.4~1.0
3
4 5
Starting
point
STITCHES
1
BAR TACK STITCH
