Parts of the embroidery unit
44 Connection plug to the machine
45 Fastener for fi tting to the machine
46 Under arm guide
47 Release button for removing the embroidery unit
48 Pivot for embroidery arm
49 Metal guide for fi tting the embroidery hoop
50 Release lever for removing the embroidery hoop
51 Embroidery arm
52 Recessed grip for raising and rotating the
embroidery arm
Parts of the embroidery hoop
53 Snap-in pin
54 Two guide pins for retaining the hoop
55 Ribs for fi tting the clips
56 Projections for placing the template
57 Retaining screw for the fabric
57
55
54
56
53
50
51
52
49
48
444546
47
