Embroidery mode - stitch-out
5
&RPPRQ(PEURLGHU\
stitch-out pop-ups
(PEURLGHU\XQLWFDOLEUDWLRQ
When the embroidery unit is attached, a pop-up asks
you to slide off the hoop and clear the machine area for
calibrating the embroidery arm. You will also be reminded
to disengage the IDT™ system and attach the embroidery
presser foot.
Note: It is very important to remove the hoop, otherwise the hoop
or the embroidery unit may be damaged while calibrating.
Attach correct hoop
If the size of the hoop attached to the machine does not
match the size displayed on screen, the machine will not
embroider. You must change the hoop to the displayed size
or change the hoop setting to the hoop size attached.
To change hoop settings, re-enter Embroidery edit and go
to select hoop.
%REELQWKUHDGORZPRYHWREREELQSRVLWLRQ"
When the bobbin thread is running low, a pop-up message
appears giving you an indication that the bobbin needs to
be changed soon. This gives you an opportunity to plan
where to stop embroidering and change the bobbin.
It is possible to embroider until the thread completely runs
out. Press Start/Stop button to continue embroidering,
without closing the bobbin thread low pop-up.
Touch cancel to remain at the current stitch position.
Touch OK to move the hoop to bobbin position. The hoop
position tab opens. Replace the empty bobbin with a full
one. Touch Current position and pull back excess needle
thread. Move a few stitches backwards using the current
stitch icons (5). Press start/stop or press your foot control
to continue embroidering.
Check Needle Thread
The machine stops automatically if the needle thread runs
out or breaks. Re-thread the needle thread, close the pop-
up, step back a few stitches and start embroidering again.
