Pfisterer MV-CONNEX 3 - Page 19

www.psterer.com 19
Drawings not to scale - for information only Size 3 | 3-S / Standard instructions wire screen / No. 040 371 001 (2014-05-08) i-01
1
1
155
1
110 160
Installation / Assembly
VIII
1
110 160
Clean roughed area.
3 1
4 1
Flame the roughened area.
Slide the smaller heat-shrink tubing over the cable to line it and shrink it
on in the roughened area.
5 1
Only with cable < 38 mm outer diameter
Again roughen the heat-shrink tubing in the shrinkage area with grit 60
emery over 110 mm.
6 1
