Phanteks ENTHOO ELITE User Manual

26
ENTHOO ELITE
PUMP INSTALLATION
INSTALLING WATER COOLING
DDC 42-50 mm
Standard D5
Swiftech MCP
EKWB D5
EHEIM
REQUIRE:
Phanteks’ pump bracket can also
be 1) mounted on a 120 mm
fan mount location or 2) onto
a 120 mm fan. This can be very useful for
positioning pump/reservoir combo solutions.
4x
REMOVE:
Please use the
pump screws
that come with your
pump to mount on
the pump bracket.
PUMP BRACKET MOUNTING HOLES:
120 mm fan mount

Phanteks ENTHOO ELITE Specifications

General

Type	Full Tower
Material	Aluminum, Steel, Tempered Glass
Expansion Slots	10
Color	Black
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Maximum CPU Cooler Height	210 mm
Maximum GPU Length	503 mm
PSU Support	ATX
Front I/O Ports	1x USB 3.1 Gen2 Type-C, 4x USB 3.0, Audio In/Out, Reset
Radiator Support	Up to 480 mm
