ENTHOO ELITE
RGB LIGHTING
1. Press (hold): Swtich LED lights On/O
2. Short Press: Choose Mode
3. Scroll (Up / Down): See Mode list.
MODE 1 - Static
MODE 2 - Brightness control
MODE 3 - Breathing
MODE 4 - Color cycle
Scroll: Select color
Scroll: Adjust brightness
Scroll: Select color
Scroll: Adjust cycle speed
MODE LIST
12V SATA input
RGB connector
(expansion)
TO PSU
TO PHANTEKS
RGB LEDSTRIPS
1,2.
3.
3.
Use the included RGB Extension
cables (in accessory bag) to reroute
the RGB connector for extra reach.
For example when connecting Phanteks RGB
watercooling products. You could also connect
an RGB LED strip and route it for external use.
