Phanteks ENTHOO ELITE - Connecting Front Panel I;O Ports

27
ENTHOO ELITE
TO GPU
CONNECTING FRONT I/O
Power SW
Power SW
Reset SW
Reset SW
H.D.D LED
HD
AUDIO
HD
AUDIO
H.D.D LED
SYSTEM 1
SYSTEM 1 SYSTEM 2
USB 3.1
TYPE-C
HDMI 2.0
SYSTEM 2
USB 3.0
HDMI 2.0
USB 3.1 TYPE-C
USB 3.0
It’s possible to connect the
“system 2” USB 3.0 connector to
“system 1” to configure 4x USB 3.0
for one single system.
Please make sure to consult your
motherboard manual before
connecting your front I/O.
