Phanteks ENTHOO ELITE User Manual

30
ENTHOO ELITE
INSTALLING VERTICAL GPU BRACKET
REQUIRE:
1.
2.
3x
TIGHTEN:
TO MOTHERBOARD PCI
1 PCI slot won’t go into the bracket. It’s possible that
using the vertical GPU bracket will unable the use
of the DVI port.
The vertical GPU bracket can’t be installed in the first PCI slot. Install
the GPU bracket in the 2nd, 3rd or 4th slot. Plug the Riser cable to your
motherboard before mounting the vertical GPU bracket.
2x

Phanteks ENTHOO ELITE Specifications

General

Type	Full Tower
Material	Aluminum, Steel, Tempered Glass
Expansion Slots	10
Color	Black
Motherboard Support	E-ATX, ATX, Micro-ATX, Mini-ITX
Maximum CPU Cooler Height	210 mm
Maximum GPU Length	503 mm
PSU Support	ATX
Front I/O Ports	1x USB 3.1 Gen2 Type-C, 4x USB 3.0, Audio In/Out, Reset
Radiator Support	Up to 480 mm
