35 | P a g e
Figure 28 – Change Parameter Values
CHANGE PARAMETER
VALUES
READ/EDIT TIMERS
OPERATING PARAMETERS
Press ENTER key to access
list of sub-menu items
18 A
READ MEASURED
VALUES
Press HOME key to access Main Menu, then use arrow keys scroll through Main Menu items.
Scroll SUB-MENU with
↓↑ arrow keys
12 A
UNDERCURRENT LMT
CURRENT UNBALANC
Press ENTER key to edit
the parameter value
Increase/decrease values
with ↓↑ arrow keys
Press ENTER key to save the new
value and return to parameter list
Press BACK key to escape without changing the
value, and return to parameters list
Press ENTER to access the list
of parameters associated with
the sub-menu
OVERCURRENT LIMT
OUTPUT VOLTAGE
Scroll parameter list
with ↓↑ arrow keys
