3.2 Source Branch Circuit Protection
Branch circuit protection must be installed in the circuit sourcing the drive. See Table 3 for
recommended circuit breaker/fuse sizing, which is based on 125% of the rated input current. Fuses may
be used for circuit protection; consult local electrical code for proper sizing. Installation of a disconnect
means within sight of the drive is recommended.
Table 3 – Fuse/Breaker Recommendations
Model
Input Current
Fuse/Breaker
SD002
20 A
25 A
SD003
30 A
40 A
SD005
42 A
55 A
SD007
58 A
75 A
SD010
69 A
90 A
SD015
92 A
115 A
SD405
30 A
40 A
SD407
37 A
50 A
SD410
42 A
55 A
SD415
56 A
70 A
2XD205
31 A
40 A
2XD207
52 A
65 A
2XD210
64 A
80 A
3.3 Installing Power Cables
CAUTION: Installations must comply with all NEC and local electrical code requirements.
Connection to input and output power is made on the power terminal block. See Table 4 for connection
descriptions and Figure 14 for terminal block locations.
Important Note About Output Filters:
Models that include a sinewave filter have a different power terminal connection configuration. Refer to
Figure 15 for connecting models with output filters.
Table 4 – Power Terminal Descriptions
Terminal Name
Description
L1, L2
Input power terminals for single-phase input
U, V, W
Output power terminals for three-phase output
BUS -
*Important* DO NOT connect power
GND
Earth safety ground
Table 5 – Power Terminal Descriptions – SD002, SD003 only
