Figure 15 - Power Terminal Location, 2XD
Control Terminals
CAUTION:
Do not route control
circuit cables near the main
motor output cables. Electrical
noise from the main motor
cables can couple onto the
cables, resulting in distortion of
control signals.
Motor Terminals if optional
sine filter is NOT installed.
Motor terminals if
sinewave is installed.
With sinewave filter
2XD Series
