34 | P a g e
ADJUSTABLE PARAMETERS
5.1 Changing Parameter Values
WARNING: When the drive is set to automatically restart after a fault, the output terminals can
energize and the load can start without warning, exposing the user to risk of serious injury. Make
certain the input is de-energized before approaching the equipment. The unit can be programmed to
automatically restart after certain faults. The factory default setting does not allow automatic restart.
Use caution if automatic restart is enabled.
The CHANGE PARAMETER VALUES function allows the user to set values for a variety of functions
including motor overload settings, number of restarts after a fault, ramp time, maximum frequency, and
more. To change parameter values:
1. Press the HOME key until CHANGE PARAMETER VALUES appears on the display.
2. Press ENTER to access this menu item.
3. There are multiple sub-menu items under CHANGE PARAMETER VALUES. Use the up and
down arrows to scroll through the sub-menu to find the item desired, then press ENTER. See
Table 14 through Table 18, for a list of parameters with a description.
4. Use the up and down arrow keys to scroll to the parameter you want to set, press ENTER,
then use the up and down arrows to select a new value for that parameter.
5. When the value you want appears on the display, press ENTER to select that value.
6. To escape the parameter without selecting or resetting the value, press the BACK key, which
will return you to the list of parameters.
Programming Tip
Press the ENTER key to move to lower levels of the menu outline or to save a new parameter value.
Press the BACK key to move to higher levels in the menu outline or to escape a parameter setting
without changing the value.
