2.2 Model Ratings
Table 1 – SD Series Model Ratings
Model
Rated
HP
Rated Input
Voltage
Rated
Input
Current
Rated Output
Voltage
Rated
Output
Current
Switching
Frequency*
Weight
SD002
2
240V
Single
Phase
20 A
240V
Three
Phase
8 A
2-8 kHz
15 lb
SD003
3
30 A
10 A
15 lb
SD005
5
42 A
18 A
20 lb
SD007
7.5
58 A
27 A
20 lb
SD010
10
69 A
33 A
20 lb
SD015
15
92 A
46 A
145 lb
SD405
5
480V
Single
Phase
30 A
480V
Three
Phase
10 A
30 lbs
SD407
7.5
37 A
13 A
30 lbs
SD410
10
42 A
18 A
35 lbs
SD415
15
56 A
24 A
40 lbs
*Factory default for Switching Frequency is 2 kHz. Switching Frequency is an adjustable parameter set
through the keypad. Weights do not include optional output filter.
Table 2 – 2XD Series Model Ratings
Model
Rated
HP
Rated Input
Voltage
Rated
Input
Current
Rated Output
Voltage
Rated
Output
Current
Switching
Frequency*
Weight
2XD205
5
240V
Single Phase
31 A
480V
Three
Phase
10 A
2-8 kHz
64 lb
2XD207
7.5
52 A
13 A
64 lb
2XD210
10
64 A
18 A
65 lb
2XD215
15
Upgraded to 1LH Series product line. See 1LHE215R
*Factory default for Switching Frequency is 2 kHz. Switching Frequency is an adjustable parameter set
through the keypad.
Weights do not include optional output filter.
