14 | P a g e
Terminal Name
Description
L1, L2
Input power terminals
BLK, BLK/YEL
2-wire output power terminals
RED, BLK/YEL, BLK
3-wire output power terminals
RED
Auxiliary/Start/Run Winding
BLK/YEL
Motor Winding Common
BLK
Main Winding
GND
Earth ground
Table 6 – Input Power Terminal Wiring Specifications
Input Power Terminals
Model
SD007, SD010, SD015,
2XD205, 2XD207,
2XD210
SD002, SD003,
SD005, SD405,
SD407, SD410
Wire Size
Torque
Wire Size
Torque
2 - 6 AWG
120 lb-in
20–6 AWG
15 lb-in
8 AWG
40 lb-in
10 - 14 AWG
35 lb-in
Table 7 – Output Power Terminal Wiring Specifications
Output Power Terminals
Model
SD007-B, SD010-B, SD015, SD405, SD407,
SD410, SD415
2XD205-O, 2XD207-O, 2XD210-O,
SD002, SD003, SD005, SD007, SD010,
2XD205, 2XD207, 2XD210
Wire Size
Torque
Wire Size
Torque
4 – 18 AWG
16 in. lbs
20–6 AWG
10.5 lb-in
