DISPLAY MESSAGE
DESCRIPTION
DEFAULT/MIN
/MAX VALUE
ANALOG SELECT
0 = I_1 ON
1 = I_2 ON
2 = I_1 ON, I_2 redundant
3 = I_2 ON, I_1 redundant
0/0/3
DISABLE MANUAL
MODE
Disables manual operation of the drive through the keypad.
Operating states are limited to AUTO and OFF. YES = MANUAL
mode disabled
YES/NO/YES
AUX1 SELECT
Programmable digital inputs. Generally used for motor Run/Stop
control.
0= RUN/STOP (closed = RUN, open = STOP)
1= Always in RUN mode (no jumper or switch required)
1/0/2
AUX2 SELECT
Programmable digital inputs. Generally used for motor Run/Stop
control.
0= RUN/STOP (closed = RUN, open = STOP)
1= Always in RUN mode (no jumper or switch required)
2= Latching relay. When the connection between the AUX
terminal and COM is opened the drive will stop the motor and
display a fault on the screen. The motor will remain stopped
even if the connection is closed. The fault must be cleared by
pressing the ENTER key.
3= Reverse Rotation. When circuit opens motor will reverse.
Function of these inputs can change when certain System
Configuration settings are chosen.
See Section 6.5, System Configuration, for additional info.
1/0/3
RTC SETUP
Real-Time Clock
MM/DD/YY HH:MM:SS
Enter button moves the character to the right, navigate up and
down to select the number
Date and Time
Note 1: This setting is typically used to control ancillary equipment in concert with motor RUN/STOP
commands. For example, to control a chlorinator so that it operates only when the motor is pumping
water.
