Philips 20PT6446 - S-Video (S-VHS) Input Connections

10
S-VIDEO (S-VHS) INPUT CONNECTIONS
T
he S(
T
he S(
T
uper)-Video connection on the rear of the TV can provide you with better picture detail and clarity for the
p
TpT
layback of accessory sources suc
h as DBS
(Digital
B
roadcast Satellite), DVD (Digital Video Disc), video games and S
-
VHS VCR (video cassette
recorder) tapes than the norma
l antenna picture connections.
NOTE :
The accessory device mus
t have an S-VIDEO
OUT(put) jack in order for you to complete the
connection on this page.
1
Connect
one end of the S-VIDEO CABLE
to the S-VIDEO jack to the back of the TV.
Connect
one end of the Audio (red and white)
CABLES to the AV In AUDIO L and R (left and
right) jacks on the re
ar of the TV.
2
Connect
th
e other end of the S-VIDEO
CABLE
to the S-VHS (S-Video
) OUT jack on
the back of the VCR. Connect
the other end
of the AUDIO (red and white) CABLES to
the
AUDIO (left and right) OUT jacks on the rear
of the VCR.
3
Turn
the
VCR and
TV
on.
4
Press the AV buttons
on the remote
control
to scroll the channels until
SVHS appears in the
upper left corner of the TV screen.
5
Now you are ready to place a pre-recorded
video tape in
the
VCR and
press the PLAY
Æ
button
75‰
L
R
S-VIDE
O
VIDE
O
AUDI
O
CV
IAV out
Y
Pb
Pr
AV in
L/Mono
VIDEO
S-VIDEO
CV
I
Y
Pb
Pr
AUDI
O
AV in
R
ANTENNA
OUT
ANTENNA
IN
VIDEO
AUDIO
IN
IN
OUTOUT
LR
S-VHS OUT
3
2
5
4
1
VOL
AV out
Audio
Cables
(Red
& White)
S-Video
Cable
VCR or External
Accessory Device
(with S-Video Output)
Back of TV
