AV (AUDIO/VIDEO) INPUT CONNECTION
T
he TV’s audio/video input jacks are for direct picture and sound connections between TV and a VCR (or similar
T
he TV’s audio/video input jacks are for direct picture and sound connections between TV and a VCR (or similar
T
device) that has audio/video output jacks. Follow steps below to connect an accessory device to the AV In Input
Tdevice) that has audio/video output jacks. Follow steps below to connect an accessory device to the AV In Input T
Jacks located at the back of the TV.
Jacks located at the back of the TV.
1
Connect the V
IDEO (yellow)
cable to the
V
IDEO AV In jack on the back of the TV.
2
C
o
nnect the AUDIO (red and white)
cables
to the AUDIO (left and right) AV
In
jacks on the re
ar
of the TV.
3
Connect the VIDEO (yellow) cable
to the
VIDEO OUT jack
at the back of the VCR
.
4
Connect the AUDIO (red and white)
cables
to the
AUDIO (left and right) O
UT
j
a
cks at the rear of the VCR.
5
Turn the VCR (accessory device) and the
TV
on.
6
Press the AV button
on the remote control
to select the AV Channel
. AV
will appear
o
n
the upper left corner of the TV screen.
7
With the VCR (or accessory de
vice) ON and
a prerecorded tape (CD, D
VD, etc
.) inserted
,
press the P
LAY
Æ
button
to view the tape
on the television.
222
75
S-VIDEO
ANTENNA
OU
T
ANTENNA
IN
VIDE
O
AUDIO
IN
IN
OU
TOUT
LR
5
3
7
Y
Pb
2
1
Video Cable
(Yellow)
Audio Cables
(Red & White)
Back of TV
Back of Typical VCR
VCR
with
Audio/Video Outputs
VOL
VIDEO
CVI
AUDI
O
AV
In
AV ou
t
R
Pr
L/Mono
