SIDE AV CONNECTIONS
A
A
udio and Video side
i
nputs are available for a quick connection of a VCR, Video camera,
gaming device
. Use the
CH+
or
CH-
butt
on on the remote control to tune these inputs.
1
Connect the V
IDEO (yellow)
cable
from
the Vi
deo output on the Camera (or accessory
de
vice) to the Video (yellow)
Input
located on
the SIDE (or FRONT) of the TV.
2
F
or Stereo Devices
:
Connect the
au
dio cable
(red and white) from the Audio Le
f
t and Right
ft and Right f
Outputs on the Camera to the Aud
io In (white)
jack on the SIDE (or FRONT)of the tel
evision
.
For Mono Devices
:
Connect one end of the
audio cable from the Audio Out jack on the
device to the Audio In (white) jack on the SIDE
of the
television.
3
Turn
the TV and the
accessory device
ON
.
4
Press the CH+ or CH- button
on the
remote control to tune the TV to the side
input jacks. “AV” will appear on the TV
screen.
5
Press the P
LAY
Æ
button on the accessory
device to view playback
, or to access the
accessory device (ca
mera, ga
ming unit, etc.).
t
n
o
r
F
S-VIDEO
VIDEOAUDIO
LEFT RIGHT
3
1
2
3
5
Side AV Inputs:
Side Jack
panel of TV
Vide
o
Cable
Audio
Cables
Jack Panel of Accessory Device
Optional
Headphones
V
ID
E O
A U D
IO
L
R
