Philips 20PT6446 - Component Video (CVI) Input Connections

11
COMPONENT VIDEO (CVI) INPUT CONNECTIONS
C
omponent Video inputs provide for the highest possible color and picture resolution on the playback of digital signal
source material, such as with DVD players. The colour difference signals (Pb, Pr) and the luminance(Y) signal are
connected and received separately, which allows for improved color bandwidth information (not possible when using
composite video or S-Video connections).
1
Connect
the Component (Y, P
b, Pr)
Vid
eo OUT
jacks from the DVD player (or
si
milar device) to the (Y, Pb, Pr
) in
(put) jack
on the TV.
When using the Component Video
Inputs
, it
is best not to connect a signal to the
AV in Video Ja
ck.
2
Connect
th
e
red and white AUDIO
CABLES
to the Audio (
left and right) output
jacks on the rear of the accessory de
vice to the
Audio (L and R) AV
In
put Jacks on the TV.
3
Turn
the
TV and the DVD (or digital
accessory device) ON.
4
Press the AV button
on the remote
control
to scroll the channels until
CVI appears in the
upper left corner of the TV screen.
5
Insert a DVD disc into the DVD player and
press the PLAY
Æ
button on the DVD Player
.
The description for the component video
connectors may differ depending on the DVD
player or accessory digital source equipment
used (for example, Y, Pb, Pr; Y, B-Y, R-Y; Y, Cr,
Cb). Although abbreviations and terms may
vary, the letters b and r stand for blue and red
color component signal. Refer to your DVD or
digital accessory user manual for definitions and
connection details.
HELPFUL HINTS
L
VIDEO
S-VIDEO
CVI
Y
Pb
Pr
AUDIO
AV
In
R
S-VIDEO
OUT
OUT
OUT
L
R
AUDIO
VIDEO
COMP VIDEO
Y
Pb
Pr
3
5
4
1
2
Component
Video Cables
(Green, Blue,
Red)
Audio
Cables
(Red &
White)
Accessory Device
Equipped with
Component Vide
o
Outputs
Back of TV
VOL
L/Mono
AUDIO
R
