Operation Guide 250ML Lighting Control Consoles
57 PRODUCT INFORMATION
PRODUCT INFORMATION
1. Specification
Model: Strand Lighting 250ML Control Console
On-Board LCD: 60x128 dot, TFT LCD with contrast adjustment
Inputs/Outputs: DMX IN: DMX512A (RDM) XLR5M Port
DMX OUT: 2 Each DMX512A (RDM) XLR5F Ports
Power Input: Connects to a Universal Power Supply (100-240VAC to VDC, provided with unit)
Power Requirement: DC 9~12V 2A Max
USB Ports: 2 Ports (Front USB port for library storage, rear USB port is specifically for desk light
connection).
Overall Dimensions: 28.9 x 12.8 x 3.2 in / 734 x 324 x 81 mm
Weight: 19.4 lbs (8.8 kgs)
Housing: Electrolytic Plate with powder finishing
734 mm / 28.9 in
80.1 mm /
3.2 in
324 mm /
12.8 in
29 mm /
1.1 in
