Service Modes, Error Codes, and Fault Finding
EN 22 EJ2.0U LA5.
Figure 5-9 “Active” to “Semi Stand-by” flowchart
action holder: MIPS
autonomous action
action holder: St-by
G_15940_046.eps
240506
Semi Standby
Active
Wait 0ms. (No need to wait here
for the 37" Sharp panel)
Switch off 12V LCD supply within a time frame of max.
1000ms after LVDS switch off.
(Viper I/O: LCD_PWR_ON)
37" 1366*768 LCD SHARP
Mute all sound outputs.
Mute all video outputs
switch off LCD lamp
Switch off LVDS signal
Switch reset-audio and sound-enable
lines high
