Philips Q552.1A - Mechanical Instructions; Cable Dressing Matisse styling (8000 series)

Mechanical Instructions
EN 9Q552.1A LA 4.
2010-Jun-25
back to
div. table
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing Matisse styling (8000 series)
4.2 Cable Dressing da Vinci styling (6000 series)
4.3 Service Positions
4.4 Assy/Panel Removal Matisse Styling (8000 series)
4.5 Assy/Panel Removal da Vinci Styling (6000 series)
4.6 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing Matisse styling (8000 series)
Note: pictures are taken from the European equivalent (with
SCART connector).
Figure 4-1 Cable dressing 42" 8000-series
18990_100_100401.eps
100401
