Philips VR550 - Page 57

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR550/02 VR550/07 VR550/16
C704 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C706 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C708 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C716 CHIP CERAMIC CAP. F Z 0.22UF/16V 1 1 1
C717 CHIP CERAMIC CAP. F Z 0.22UF/16V 1 1 1
C771 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C772 ELECTROLYTIC CAP. 10UF/16V M H7 1 1 1
C773 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1
C774 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1
C775 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1
C776 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1
C777 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1
C778 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1
C851 CHIP CERAMIC CAP.(1608) CH J 22PF/50V 1 1 1
C852 CHIP CERAMIC CAP.(1608) CH J 22PF/50V 1 1 1
C853 CHIP CERAMIC CAP.(1608) B K 4700PF/50V 1 1 1
C854 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
C855 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C856 CHIP CERAMIC CAP. CH J 180PF/50V 1 1 1
C859 ELECTROLYTIC CAP. 47UF/6.3V M H7 1 1 1
C862 CHIP CERAMIC CAP.(1608) B K 0.01UF/50V 1 1 1
CONNECTORS
CN701 9965 000 23355 AFV PCB ASSEMBLY CPU2900/G470 1
CN701 9965 000 23385 AFV PCB ASSEMBLY CPU2900/G471 1 1
DIODES
D001 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D002 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D003 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D004 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D005 5322 130 34979 RECTIFIER DIODE BA159 1 1 1
D006 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D007 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D008 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D009 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D011 4822 130 1165
4
RECTIFIER DIODE BA158 1 1 1
D012 4822 130 8388
3
RECTIFIER DIODE FR202-B/P 1 1 1
D013 4822 130 8388
3
RECTIFIER DIODE FR202-B/P 1 1 1
D014 4822 130 32715 SCHOTTKY BARRIER DIODE SB340 1 1 1
D015 9965 000 23356 ZENER DIODE DZ-18BSBT265 1 1 1
D018 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D018 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1 1 1
D019 9965 000 14881 ZENER DIODE DZ-6.8BSBT265 1 1 1
D021 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D021 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1 1 1
D051 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D052 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D053 4822 130 3193
3
RECTIFIER DIODE 1N4005 1 1 1
D055 PCB JUMPER D0.6-P10.0 1 1 1
D056 9965 000 08649 ZENER DIODE DZ-5.6BSCT265 1 1 1
D057 9965 000 0928
3
ZENER DIODE DZ-10BSBT265 1 1 1
D058 9965 000 23356 ZENER DIODE DZ-18BSBT265 1 1 1
D153 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D154 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D155 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D156 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D301 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D501 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D502 9965 000 05250 LED SIR-563ST3F P 1 1 1
D552 4822 130 1009
4
ZENER DIODE MTZJT-777.5A 1 1 1
D553 4822 130 30621 SWITCHING DIODE 1N4148M 1 1 1
D701 9965 000 0918
3
ZENER DIODE DZ-33BSDT265 1 1 1
MISCELLANEOUS
F001
h
4822 070 31602 FUSE T1.6AL/250V 1 1 1
FH001 4822 256 10461 FUSE HOLDER MSF-015 1 1 1
FH002 4822 256 10461 FUSE HOLDER MSF-015 1 1 1
1-16-4
