ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR550/02 VR550/07 VR550/16
FP562 9965 000 2335
7
LED DISPLAY LFU-4421-2003
A
111
IC’
s
IC001
h
4822 130 11655 PHOTOCOUPLER LTV-817B-F 1 1 1
IC301 9965 000 12180 IC:Y/C/A LA71750EM-MPB-E 1 1 1
IC451 9965 000 16618 IC:HIFI LA72648M-MPB-E 1 1 1
IC501 9965 000 23358 SYSCON IC M3776AMCA-AB4GP 1 1 1
IC503 9965 000 16620 IC:EEPROM CAT24WC02JI 1 1 1
IC561 9965 000 1218
3
IC:LED DRIVER PT6958-FN-TP 1 1 1
IC771 9965 000 1218
4
IC:COMPARATOR KIA339F EL 1 1 1
COILS
J902 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.
3
111
JW001 9965 000 13795 FLAT CABLE, 11P AWG26#2651/P1.25/150 1 1 1
JW002 9965 000 13795 FLAT CABLE, 11P AWG26#2651/P1.25/150 1 1 1
L001 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.
3
111
L002 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.
3
111
L003
h
9965 000 13005 LINE FILTER 56MH TLF14CB5630R2 1 1 1
L009 9965 000 0562
7
CHOKE COIL 47UH-
K
111
L010 9965 000 0562
7
CHOKE COIL 47UH-
K
111
L012 9965 000 13681 INDUCTOR 100UH-J-5F
T
111
L251 9965 000 08652 INDUCTOR 5.6UH-K-26
T
111
L301 4822 157 10649 INDUCTOR(100UH K) LAP02TA101
K
111
L403 9965 000 05705 INDUCTOR 47UH-K-5F
T
111
L451 9965 000 05705 INDUCTOR 47UH-K-5F
T
111
L452 9965 000 16621 INDUCTOR 27UH-K-5F
T
111
L501 4822 157 10649 INDUCTOR(100UH K) LAP02TA101
K
111
L561 9965 000 0570
4
INDUCTOR 68UH-K-26
T
111
L562 4822 157 63316 INDUCTOR 56UH-K-26
T
111
L701 4822 157 10332 PCB JUMPER D0.6-P5.0 1 1 1
L704 4822 157 11511 INDUCTOR 15UH-K-26
T
111
L851 9965 000 08629 INDUCTOR 1.8UH-K-26
T
111
PS503 9965 000 12189 PHOTO INTERRUPTER RPI-302C70 1 1 1
TRANSISTOR
S
Q001 9965 000 17186 FET 2SK3566 1 1 1
Q002 4822 130 1092
3
TRANSISTOR KTC3199(BL) 1 1 1
Q003 4822 130 1092
3
TRANSISTOR KTC3199(BL) 1 1 1
Q004 4822 130 10462 TRANSISTOR KTA1267(GR) 1 1 1
Q051 4822 130 42292 RES. BUILT-IN TRANSISTOR KRA104M 1 1 1
Q052 9965 000 2337
7
RES. BUILT-IN TRANSISTOR KRC103M 1 1 1
Q053 4822 130 1010
3
TRANSISTOR KTC3199(Y) 1 1 1
Q054 9965 000 11122 TRANSISTOR KTC3205(Y) 1 1 1
Q055 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1
Q056 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1 1 1
Q057 9965 000 12190 TRANSISTOR KTA1281(Y) 1 1 1
Q058 9965 000 2337
7
RES. BUILT-IN TRANSISTOR KRC103M 1 1 1
Q059 9965 000 2337
7
RES. BUILT-IN TRANSISTOR KRC103M 1 1 1
Q153 4822 130 1010
3
TRANSISTOR KTC3199(Y) 1 1 1
Q351 9965 000 16622 CHIP TRANSISTOR KTA1504GR-RT
K
111
Q352 4822 130 1010
3
TRANSISTOR KTC3199(Y) 1 1 1
Q401 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1
Q402 4822 130 42292 TRANSISTOR KTC3203(Y) 1 1 1
Q403 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1 1 1
Q405 9965 000 1662
3
CHIP TRANSISTOR FMG4A T148 1 1 1
Q406 9965 000 1368
3
CHIP TRANSISTOR KTC3875Y-RTK 1 1 1
Q451 9965 000 1662
4
CHIP TRANSISTOR KRC103S RTK 1 1 1
Q501 4822 130 1092
3
TRANSISTOR KTC3199(BL) 1 1 1
Q503 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1 1 1
Q551 4822 130 1092
3
TRANSISTOR KTC3199(BL) 1 1 1
Q552 9965 000 2337
7
RES. BUILT-IN TRANSISTOR KRC103M 1 1 1
Q771 4822 130 1010
3
TRANSISTOR KTC3199(Y) 1 1 1
Q772 4822 130 1010
3
TRANSISTOR KTC3199(Y) 1 1 1
RESISTORS
R001 9965 000 0865
3
CARBON RES. 1/2W K 5.6M OHM 1 1 1
R002 9965 000 08635 METAL OXIDE FILM RES. 1W J 150K OHM 1 1 1
R003 CARBON RES. 1/4W J 1M OHM 1 1 1
R004 CARBON RES. 1/4W J 1M OHM 1 1 1
