ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
VR550/02 VR550/07 VR550/16
R787 CHIP RES.(1608) 1/10W J 2.2K OHM 1 1 1
R851 CHIP RES.(1608) 1/10W J 1.5K OHM 1 1 1
R852 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1
R853 CHIP RES.(1608) 1/10W J 1K OHM 1 1 1
RS501 9965 000 12191 REMOTE RECEIVER MIM-93M9DK
F
111
SA001
h
9965 000 08602 SURGE ABSORBER CNR-10D471
K
111
SWITCHES
SW501 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW502 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW503 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW505 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW506 9965 000 16625 LEAF SWITCH MXS01830MVP0 1 1 1
SW507 9965 000 23359 ROTARY MODE SWITCH SSS-53MD 1 1 1
SW509 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW510 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW511 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
SW512 4822 276 1395
4
TACT SWITCH KSM0614B 1 1 1
T001
h
9965 000 23360 SWITCHING TRANSFORMER 3733-S01 1 1 1
TP301 PCB JUMPER D0.6-P10.0 1 1 1
TP501 PCB JUMPER D0.6-P6.0 1 1 1
TP502 PCB JUMPER D0.6-P5.0 1 1 1
TP506 PCB JUMPER D0.6-P5.0 1 1 1
TP507 PCB JUMPER D0.6-P6.0 1 1 1
TU701 9965 000 23361 TUNER UNIT TMDG2-661
A
11
TU701 9965 000 23386 TUNER UNIT TMDG2-662
A
1
VR501 9965 000 05260 CARBON P.O.T. 100K OHM B 1 1 1
X301 9965 000 05629 X’TAL 4.433619MH
Z
111
X501 9965 000 1219
4
X’TAL 12.000MH
Z
111
X502 9965 000 12288 X’TAL 32.768KHZ(20PPM
)
111
JACK CBA
(
MCV-C
)
2L022 4822 502 30752 SCREW, P-TIGHT M3X10 WASHER HEAD+ 1 1 1
A5 9965 000 16629 JACK BOARD(2-21P) HE470ED 1 1 1
CAPACITOR
S
C101 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1
C102 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1
C103 CHIP CERAMIC CAP.(1608) CH J 470PF/50V 1 1 1
C104 CHIP CERAMIC CAP.(1608) CH J 470PF/50V 1 1 1
C105 CHIP CERAMIC CAP.(1608) F Z 0.1UF/50V 1 1 1
C107 ELECTROLYTIC CAP. 1UF/50V M H7 1 1 1
C108 CHIP CERAMIC CAP. B K 1000PF/50V 1 1 1
C109 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1
C110 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1
C111 CHIP CERAMIC CAP.(1608) CH J 470PF/50V 1 1 1
C112 CHIP CERAMIC CAP.(1608) CH J 470PF/50V 1 1 1
C113 CHIP CERAMIC CAP. B K 2200PF/50V 1 1 1
C115 ELECTROLYTIC CAP. 100UF/16V M H7 1 1 1
C116 ELECTROLYTIC CAP. 470UF/6.3V M 1 1 1
C117 ELECTROLYTIC CAP. 470UF/6.3V M 1 1 1
DIODES
D101 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D102 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D103 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D104 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D105 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
D106 9965 000 12178 ZENER DIODE DZ-11BSAT265 1 1 1
CONNECTORS
JK101 9965 000 1219
7
RGB CONNECTOR MRC-021V-01 1 1 1
JK102 9965 000 1219
7
RGB CONNECTOR MRC-021V-01 1 1 1
COILS
L101 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.
3
111
L102 4822 526 10685 BEAD CORE B16 RH 3.5X10X1.
3
111
TRANSISTOR
S
Q101 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1
Q102 4822 130 42959 TRANSISTOR KTA1266(GR) 1 1 1
RESISTORS
1-16-9
